Hyperedge models

amorem supports relational hyper event models (RHEMs), the extension of REMs from dyadic (sender, receiver, time) events to set-valued (I, J, time) hyperedges, where I is a set of senders and J is a set of receivers. Following Boschi, Lerner & Wit (2025), a single event can involve several actors per axis: a paper authored by a co-author set citing a set of references, an e-mail sent to several recipients at once, or a multi-actor meeting (J = ∅). The code on this page runs when the page is built.

Data model

hl <- hyperedge_log(
  I    = list(c("alice", "bob"), c("alice", "carol"), c("bob", "carol")),
  J    = list(c("paperA"),        c("paperA", "paperB"), c("paperB")),
  time = c(1.0, 2.5, 4.0))

is_hyperedge_log(hl)
#> [1] TRUE
hyperedge_sizes(hl)
#>              I              J time size_I size_J
#> 1   alice, bob         paperA  1.0      2      1
#> 2 alice, carol paperA, paperB  2.5      2      2
#> 3   bob, carol         paperB  4.0      2      1

Function	Purpose
`hyperedge_log(I, J, time)`	Validating constructor; sorts by time
`is_hyperedge_log(x)`	Structural predicate
`as_hyperedge_log(event_log)`	Promote a dyadic log (each row becomes a singleton on each axis)
`as_dyadic_log(h)`	Inverse; succeeds only when `\|I\| = \|J\| = 1` on every row
`hyperedge_sizes(h)`	Adds `size_I` and `size_J` columns

A dyadic log and its hyperedge form convert into each other:

dy <- data.frame(sender = c("a", "b"), receiver = c("b", "c"), time = c(1, 2))
h  <- as_hyperedge_log(dy)
h$I
#> [[1]]
#> [1] "a"
#>
#> [[2]]
#> [1] "b"
as_dyadic_log(h)
#>   sender receiver time
#> 1      a        b    1
#> 2      b        c    2
try(as_dyadic_log(hl))   # rows with two senders are not dyadic
#> Error in as_dyadic_log(hl) :
#>   Cannot convert to a dyadic log: 3 event(s) have non-singleton sender or receiver sets.

For undirected hyperevents (e.g. multi-actor meetings), pass J = list(character(0), ...) and use the actor-only simulator below.

Subset repetition

The hyperedge-native covariates of the paper (eq. 3-4) count how often parts of a focal hyperedge have occurred together before time t:

# past events containing both {alice, bob} and {paperA}
hyperedge_activity(hl, I = c("alice", "bob"), J = "paperA", t = 5)
#> [1] 1

# share-weighted repetition over the size-2 subsets of I, paired with paperA
hyperedge_subrep(hl, I = c("alice", "bob", "carol"), J = "paperA",
                 t = 5, rho = 2, l = 1)
#> [1] 0.6666667

hyperedge_subrep(rho, l) averages, over all sender subsets of size rho and receiver subsets of size l, the number of past events that contain both subsets. For dyadic events with |I| = |J| = 1, rho = 1, l = 1 is the count of past events on the same dyad.

Feature engine

hyperedge_features() is the hyperedge analogue of endogenous_features(). It evaluates each statistic at every row of the log, using the events strictly before that row:

hyperedge_features(hl, stats = c("activity", "subrep_1_1", "subrep_2_1"))
#>              I              J time activity subrep_1_1 subrep_2_1
#> 1   alice, bob         paperA  1.0        0       0.00          0
#> 2 alice, carol paperA, paperB  2.5        0       0.25          0
#> 3   bob, carol         paperB  4.0        0       0.50          0

Stat name	Meaning
`"activity"`	`hyperedge_activity()` on each row’s `(I, J)`
`"subrep_<rho>_<l>"`	directed subset repetition (`NA` when the row has fewer than `rho` senders or `l` receivers)
`"subrep_<rho>"`	undirected subset repetition (`l = 0`)
a name from the dyadic catalogue	delegated to `endogenous_features()` after `as_dyadic_log()`; requires every row to be dyadic

Case study · multi-recipient e-mail

In radoslaw_email (internal e-mail of a manufacturing company), an e-mail sent to several recipients appears as one row per recipient with the same sender and time stamp. Grouping the rows by sender and time gives a directed hyperevent: I = {sender}, J = {recipients}. We use the first 7 days.

data(radoslaw_email)
origin_email <- attr(radoslaw_email, "unix_origin")
x <- radoslaw_email[radoslaw_email$time < 7 &
                    radoslaw_email$sender != radoslaw_email$receiver, ]
key <- paste(x$sender, x$time)
first <- !duplicated(key)
J_sets <- lapply(split(as.character(x$receiver),
                       factor(key, levels = unique(key))), unique)
email_hl <- hyperedge_log(I = as.list(as.character(x$sender[first])),
                          J = unname(J_sets), time = x$time[first])
email_hl <- hyperedge_sizes(email_hl)
c(rows = nrow(x), hyperevents = nrow(email_hl),
  multi_recipient = sum(email_hl$size_J > 1),
  actors = length(unique(c(x$sender, x$receiver))))
#>            rows     hyperevents multi_recipient          actors
#>            2794            1808             248             142

The multi-recipient e-mails of the busiest hour drawn as a hypergraph, actors coloured by their group in the week's e-mail network

Of the 1,808 e-mails, 248 (14%) have more than one recipient; they account for 44% of the 2,794 rows of the dyadic log. The largest recipient set has 135 members. The figure draws the multi-recipient e-mails of the busiest hour; over the week, 54% of the recipients of multi-recipient e-mails belong to the sender’s group of the e-mail network.

The animation steps through the week in 3-hour windows of Warsaw time. The busiest window, Wed 06 Jan 09:00–12:00, holds 25 of the 248 multi-recipient e-mails, and 24 of the 49 windows have none.

The single-recipient e-mails form an ordinary dyadic log again, so the dyadic catalogue applies to them directly:

single <- email_hl[email_hl$size_J == 1, c("I", "J", "time")]
class(single) <- class(email_hl)
dy_single <- as_dyadic_log(single)
head(endogenous_features(dy_single, stats = c("reciprocity_count", "recency")), 3)
#>   sender receiver     time reciprocity_count      recency
#> 1     39       81 1.499028                 0           NA
#> 2     39       81 1.499595                 0 0.0005671296
#> 3    112      136 1.519433                 0           NA

A size-matched case-control fit

amorem does not yet sample non-events for hyperevents, so the case-control design is built here by hand: for each e-mail, one control hyperedge with the same number of recipients, a sender drawn uniformly from the actors and a recipient set drawn uniformly from the other actors (matching on cardinality, as in Section 3.3 of the paper). Three statistics are evaluated for the event and the control at the event’s time, from the e-mails strictly before it:

sender activity: past e-mails from the sender (hyperedge_subrep(rho = 1, l = 0));
repetition: past e-mails from the sender to each recipient, averaged over the recipients (hyperedge_subrep(rho = 1, l = 1));
reciprocity: past e-mails from each recipient to the sender, averaged over the recipients (hyperedge_activity() with the roles swapped).

hstats <- function(I, J, t) c(
  sender_activity = hyperedge_subrep(email_hl, I, J, t, rho = 1, l = 0),
  repetition      = hyperedge_subrep(email_hl, I, J, t, rho = 1, l = 1),
  reciprocity     = mean(vapply(J, function(j)
                      hyperedge_activity(email_hl, I = j, J = I, t = t), 0)))

set.seed(11)
actors <- sort(unique(c(unlist(email_hl$I), unlist(email_hl$J))))
rows <- lapply(seq_len(nrow(email_hl)), function(i) {
  I <- email_hl$I[[i]]; J <- email_hl$J[[i]]; t <- email_hl$time[i]
  s_c <- sample(actors, 1)
  J_c <- sample(setdiff(actors, s_c), length(J))
  rbind(data.frame(stratum = i, event = 1L, t(hstats(I, J, t))),
        data.frame(stratum = i, event = 0L, t(hstats(s_c, J_c, t))))
})
cc <- do.call(rbind, rows)
for (v in c("sender_activity", "repetition", "reciprocity"))
  cc[[paste0("log_", v)]] <- log1p(cc[[v]])

w <- widen_case_control(cc, covariates = c("log_sender_activity",
                                           "log_repetition", "log_reciprocity"))
fit <- rem(~ log_sender_activity + log_repetition + log_reciprocity,
           data = w, method = "gam")
est <- summary(fit)$p.table[, c("Estimate", "Std. Error")]
round(est, 3)
#>                     Estimate Std. Error
#> log_sender_activity    0.551      0.081
#> log_repetition         1.344      0.254
#> log_reciprocity        4.377      0.323

Estimated effects of sender activity, repetition and reciprocity with 95% intervals

All three statistics enter on the log(1 + count) scale. Holding the other two fixed, the log-rate of an e-mail changes by 0.55 (standard error 0.08) per unit of sender activity, by 1.34 (s.e. 0.25) per unit of repetition and by 4.38 (s.e. 0.32) per unit of reciprocity. A control is drawn from all actor sets of the same size, so these coefficients compare each e-mail with an arbitrary hyperedge of its size; a design that also matches on the sender would isolate the recipient-side effects.

Two-mode directed simulator

For citation-style data (Boschi et al. 2025 Section 5), simulate_directed_hyperedge_events() draws sender and receiver sets from two actor pools. Supported endogenous statistics: "size_I", "size_J", "activity", "subrep_<rho>_<l>". A 150-event sweep on 4 senders × 4 receivers, varying the endogenous terms one at a time:

specs <- list(
  "no effect"         = c(),
  "size_I = -0.6"     = c(size_I = -0.6),
  "subrep_1_1 = 0.8"  = c(subrep_1_1 = 0.8),
  "both"              = c(size_I = -0.6, subrep_1_1 = 0.8))
sims <- lapply(specs, function(eff) {
  set.seed(2)
  simulate_directed_hyperedge_events(
    n_events = 150, senders = paste0("author", 1:4),
    receivers = paste0("paper", 1:4), max_size_I = 3, max_size_J = 3,
    baseline_rate = 0.3,
    endogenous_stats = if (length(eff)) names(eff) else NULL,
    endogenous_effects = if (length(eff)) eff else NULL)
})
sizes <- lapply(sims, hyperedge_sizes)
sweep <- data.frame(
  mean_size_I = vapply(sizes, function(s) mean(s$size_I), 0),
  mean_size_J = vapply(sizes, function(s) mean(s$size_J), 0),
  share_I_1   = vapply(sizes, function(s) mean(s$size_I == 1), 0))
round(sweep, 2)
#>                  mean_size_I mean_size_J share_I_1
#> no effect               2.02        1.91      0.30
#> size_I = -0.6           1.71        2.07      0.47
#> subrep_1_1 = 0.8        1.19        1.14      0.85
#> both                    1.07        1.10      0.95

The 150 simulated events under each of the four specifications, one column per event with its senders and receivers marked

Each panel shows the 150 events of one simulation, one column per event: teal marks are its senders (authors A1–A4), purple marks its receivers (papers P1–P4, shaded band), so the number of teal marks in a column is the sender-set size. With subrep_1_1 = 0.8 every event from event 39 on repeats the same sender and receiver sets; with both effects, every event from event 18 on.

With no endogenous effect, 30% of the events have a single sender. A negative size_I effect raises that share to 47%; a positive subrep_1_1 effect raises it to 85%, since it reinforces the sender-receiver pairs that have already occurred; both effects together give 95%.

The simulator enumerates every candidate (I, J) for every event, so the cost per event grows exponentially with the actor pools; it is practical for small universes (about 10 actors per side, max_size ≤ 3).

Undirected meeting simulator

For undirected multi-actor meetings (Section 4 of the paper), simulate_hyperedge_events() enumerates every subset of actors of size min_size..max_size, scores each from the event history, draws an event proportional to its exponentiated score, and waits an exponential time with rate equal to the total score. The output is a hyperedge log with empty receiver sets.

set.seed(5)
meet <- simulate_hyperedge_events(
  n_events           = 150,
  actors             = LETTERS[1:5],
  max_size           = 3,
  baseline_rate      = 0.3,
  endogenous_stats   = c("subrep_2", "size"),
  endogenous_effects = c(subrep_2 = 0.6, size = -0.3))
pairs <- utils::combn(LETTERS[1:5], 2, simplify = FALSE)
pair_counts <- vapply(pairs, function(p)
  hyperedge_activity(meet, I = p, t = Inf), 0)
names(pair_counts) <- vapply(pairs, paste, "", collapse = "")
top <- names(which.max(pair_counts))
sort(pair_counts, decreasing = TRUE)[1:4]
#>  AD  AE  DE  BC
#> 143   4   4   3

Co-attendance network of the five actors and the running count of meetings for two pairs

With subrep_2 = 0.6, a pair that meets is more likely to meet again. Of the 150 meetings, 143 contain the pair {A, D}, and 0 contain the pair {A, C}.

Time-varying and non-linear effects on hyperevents

simulate_directed_hyperevents_tvnl() simulates directed hyperevents between groups of senders and groups of receivers, where a group’s covariate is the mean of its members’ attributes. The sender-group covariate has a time-varying effect $\alpha(t)$ and the receiver-group covariate a non-linear effect $f(x)$ . It returns a case-control table, which widen_case_control() and rem() fit with tv() and nl() terms:

set.seed(1234)
sa <- setNames(rnorm(4, 5, 1.5), paste0("S", 1:4))
ra <- setNames(rnorm(4, 3, 2.0), paste0("R", 1:4))
d  <- simulate_directed_hyperevents_tvnl(sa, ra, horizon = 4, n_controls = 1)
table(d$event)
#>
#>    0    1
#> 3505 3505
wd <- widen_case_control(d, stratum = "event_id",
                         covariates = c("cov_sender", "cov_receiver", "event_time"))
fit_tvnl <- rem(~ tv(cov_sender, k = 6) + nl(cov_receiver, k = 6),
                data = wd, method = "gam", time = "event_time")

Estimated time-varying and non-linear effects with 95% bands against the true effects

Solid lines are the estimates with 95% bands, dashed lines the true effects; the non-linear effect is identified up to an additive constant, so its truth is drawn centred.

Smooth effects on hyperedge features

Once features are computed on a case-control table, linear, tv(), nl() and tvnl() specifications are fitted with rem() as for dyadic data — see Estimation. The case-control likelihood is equation 8 of Boschi et al. (2025).
